Nitrogen / Oxygen / Argon Stainless Steel 316 Semi-Automatic Changeover Gas Conrol Panel
R1100 Semi-Automatic Changeover Gas Conrol Panel
R1100 serie semi-automatic switch device applied two pipe line supply，that is main cylinder supply set and spare cylinder set.the device makes a stable output by using secondary pressure regulator
Product Parameter of Nitrogen / Oxygen / Argon Stainless Steel 316 Semi-Automatic Changeover Gas Conrol Panel
| Design Features of Semi-Automatic Changeover Gas Conrol Panel | |
| 1 | Used R11 serie pressure reducing regulator |
| 2 | Metal-to-metal diaphragm seal |
| 3 | Inlet fitted with check valve |
| 4 | Wall mounting |
| Material of Semi-Automatic Changeover Gas Conrol Panel | |
| 1 | Body：316L |
| 2 | Diaphragm：316L |
| 3 | Seat：PCTFE |
| 4 | Stem:316L |
| Specification of Semi-Automatic Changeover Gas Conrol Panel | ||
| 1 | macimum inlet pressure | 3000psig |
| 2 | output pressure | 0~25，0~50，0~10，0~200psig |
| 3 | working temperature | -40~+165℉（-40~+47℃） |
| 4 | Cv | 0.06 |
| R1100 | L | 150 |
|
Name of Series
|
Body Material | Pressure Contol Range |
| R1100 series | L:316L | 25:0~25psig |
| B：brass | 50:0~50psig | |
|
|
100:0~100psig | |
| 200:0~200psig |
1. who are we?
We are based in Guangdong, China, start from 2011,sell to Southeast Asia(20.00%),Africa(20.00%),Eastern Asia(10.00%),Mid East(10.00%),Domestic Market(5.00%),South Asia(5.00%),Northern Europe(5.00%),Central America(5.00%),Western Europe(5.00%),South America(5.00%),Eastern Europe(5.00%),North America(5.00%). There are total about 51-100 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
pressure regulator,Tube fittings,solenoid valve,Needle valve,check valve
4. why should you buy from us not from other suppliers?
We have a couple of years with professional engineers and dedicated technicians.can provide security products for you
5. what services can we provide?
Accepted Delivery Terms: FOB,CIF,EXW；
Accepted Payment Currency:USD,CNY;
Accepted Payment Type: T/T,L/C,Western Union;
Language Spoken:English,Chinese
