AFK Ammonia Single Stage Pressure Regulator 200 bar

Short Description:

Brand Name:AFKLOK

Model Number:R11

Material:stainless steel 316

Application:Cutting Industrial

Inlet and outlet connection:1/4in male to 1/4in Ferrule

Max Inlet Pressure:500,3500psi

Outlet pressure:0~25,0~50,0~100,0~250,0~500psi

Working temp:-40℉~+446℉(-40℃~+230℃)

Certificate:ISO9001

CV:0.09 (3500psi)

CV: 0.15 (600psi)

Send email to us

Product Detail

Video

Parameters

Ordering Information

Applications

Product Tags

Product Description of Customized Adjustable Air Propane Gas Pressure Regulator Single Stage Gas Regulator

Features of Customized Adjustable Air Propane Gas Pressure Regulator Single Stage Gas Regulator

Single-stage diaphragm structure
Corrugated diaphragm design for excellent
sensitivity and cycle life
Suitable for corrosive and toxic gases
20 μm filter element installed at inlet
Oxygen environment options are available

Previous: Dual Stage Special Gas High Pressure Regulator with Gauge 3000psi DIN Cylinder Connector

Next: 1/8in 1/4in 3/8in 1/2in Industrial High Pressure Stainless Steel Gas Non Return Check Valve

Specification of Customized Adjustable Air Propane Gas Pressure Regulator Single Stage Gas Regulator

Technical Data of Oxygen Regulator Industrial Steel Single Stage Regulator No Gauge with Inlet and Outlet Connection 1/4in Male to 1/4in Ferrule
1	Maximun Input Pressure	500,3000 psig
2	Output Pressure Range	0~25, 0~50, 0~100, 0~250, 0~500 psig
3	Safety Testing Pressure	1.5 times of maximum input pressure
4	Working Temperature	-40°F~ +165°F (-40°C~ +74°C )
5	Leakage Rate	2×10-8 atm cc/sec He
6	CV Value	0.08

Material List of Oxygen Regulator Industrial Steel Single Stage Regulator No Gauge with Inlet and Outlet Connection 1/4in Male to 1/4in Ferrule
1	Body	SS316L, brass, nickel plated brass ( Weigh :0.9kg)
2	Cover	SS316L, brass, nickel plated brass
3	Diaphragm	SS316L
4	Strainer	SS316L(10um)
5	Valve Seat	PCTFE,PTFE,Vespel
6	Spring	SS316L
7	Plunger Valve Core	SS316L
