Air Ar NH3 HCL He H2 N2 O2 CO2 Gas Pressure Regulator Single Gauge Single Stage Stainless Steel 316 Pressure Regulator 200psi

Short Description:

Product Name:Single Stage Stainless Steel 316 Pressure Regulator

Material:Stainless Steel

Application:Industrial

CV:1.8

Inlet And Outlet Connection:3/4″NPT F

Outlet Pressure Range:200PSI

Weight:2.5

MOQ:1 Pcs

Max Inlet Pressure:500,1500PSI

Outlet Pressure:0~15,0~25,0~75,0~125psi

Send email to us

Product Detail

Video

Parameters

Ordering Information

Applicable scenarios

Packing & Delivery

FAQ

Product Tags

Product Description of CO2 Gas Pressure Regulator

R13 series stainless steel pressure reducer , single-stage diaphragm pressure reducing structure , satinless steel diaphragm pressure transmission , stable output pressure , mainly decomposes large flow gas systems , suitable for pure gas , standard gas , corrosive gas , etc

Typical applications:Gas purge system,Special gases,Gas bus-bar,Petrochemical industry

Previous: Supply OEM/ODM Rsc-A6 RO Machines Plastic Solenoid Valve for Water

Next: High Pressure Argon hydrogen gas Single Stage Pressure Regulator

Design Features of CO2 Gas Pressure Regulator
1	Structure	Single-stage pressure-reducing structure
2	Metal type	Metal diaphragm seal
3	Body thread	input & output connection 3/4”NPT(F)
4	Gauge and safe valve connection	1/4”NPT(F)
5	Clean	Easy to clean internal structure
6	Internal accessories	Filter element installed internally
7	Mounting form	Panel mounting and wall mounting available

Material of CO2 Gas Pressure Regulator
1	Body	316L , Brass
2	Bonnet	316L , Brass
3	Diaphragm	316L(10um)
4	Strainer	316L
5	Seat	PCTFE , PTFE . Vespel
6	Spring	316L
7	Stem	316L

Ordering Information of CO2 Gas Pressure Regulator
R13	L	B	E	H	G	04	04	P
Item	Body Materia	Body hole	Inlet pressure	Outlet pressure	Pressure gauge	Inlet size	Outlet size	Options
R13	L:316	A	E:1500psi	H:0~125psig	G:MPa gauge	04:1/2”NPT(F)	04:1/2”NPT(F)	P:Panel mounting
	B:Brass	B	F:500psi	J:0~75psig	P:Psig/bar gauge	05:1/2”NPT(M)	05:1/2”NPT(M)	R:With relief valve
		D		L:0~25psig	W:No gauge	06:3/4”NPT(F)	06:3/4”NPT(F)
		G		M:0~15psig		13:1/2”OD	13:1/2”OD
		J				14:3/4”OD	14:3/4”OD
		M				Other type is available	Other type is available

There are 259 single gases of special gases, including 115 electronic gases, 63 organic gases, 35 inorganic gases, 29 halocarbon gases and 17 isotope gases. What are the special gases used for? Let’s have a look!

The electronics industry is a high-tech industry that promotes the development of science and technology today. Because of the many varieties of gases used and the high quality requirements, these gases used in the electronics industry are collectively called electronic special gases, which are high-tech industries with high technological content, high investment and high added value.

Q: Are you trading company or manufacturer?
A: We are original manufacturer. We can do OEM/ODM business.Our company mainly produces Pressure Regulator.
Q: How long is your delivery time?
A: Group buying delivery time: 30-60 days; General delivery time: 20 days.
Q: What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery.
Q: What is the warranty ?
A: The free warranty is one year from the day of Commissioning qualified.If there is any fault for our products within the free warranty period, we will repair it and change the fault assembly for free.
Q: How can I get your catalogue and price list?
A: Please let us know your email or contact us from website directly for our catalogue and price list;
Q: Can I negotiate the prices?
A: Yes, we may consider discounts for multiple container load of mixed goods.
Q: How much will the shipping charges be?
A: It depends on the size of your shipment and the method of shipping.
We will offer the charge to you as you requested.
